Leadermac Speedmac 923

Verkocht

Leadermac Speedmac 923

Hardinxveld-Giessendam, Nederland

Beschrijving

LEADERMAC, type Speedmac 923 Status: SOLD LEADERMAC moulder, type Speedmac 923 Manufacture year 2008 Machine specifications: - Planing width 20 - 230 mm - Planing height 10 - 150 mm - Cardan driven feeding system, motor 18.5 kW - Max. feed speed 80 m/min Spindle layout: 1. Horizontal spindle bottom, motor 11 kW 2. Vertical spindle right, motor 11 kW 3. Vertical spindle left, motor 11 kW 4. Horizontal spindle top, motor 22 kW 5. Vertical spindle right motor 11 kW 6. Vertical spindle left, motor 11 kW 7. Horizontal spindle bottom, motor 18.5 kW 8. Horizontal spindle top, motor 22 kW 9. Horizontal spindle bottom, motor 37 kW - All spindles frequency controlled, 4000 - 8000 rpm - Front bearing for spindle 1, 4, 7, 8 and 9 - Jointer for spindle 5, 6, 7 and 8 - 4 pc. digital positioning controllers for spindle 3, 4, 6 and 8 - Bed plates hard chrome - 8 pc. driven table rollers - Spindle diameter 50 mm - Pressure shoe behind spindle 7 and 9 electric adjustable - With tooling and accessories

Specificaties

FabrikantLeadermac
ModelSpeedmac 923
ConditieGebruikt
